SAMSUNG AR12TVHABWK/GA INVERTER TRIANGLE WALL-MOUNT AIR CONDITIONE WITH WIND-FREE COOLING TECNOLOGY , 1.5HP

11,599.00

Close
Price Summary
  • 11,599.00
  • 11,599.00
  • 11,599.00
In Stock
Highlights:
  • Capacity
    • Capacity (Cooling, Btu/hr)12000 Btu/hr
    • Capacity (Cooling, Min – Max, Btu/hr)4,000 ~ 14,000 Btu/hr
    • Capacity (Cooling, kW)3.52 kW
    • Capacity (Cooling, Min – Max, kW)1.17 ~ 4.1 kW
  • Energy Efficiency
    • EER (Cooling, W/W)3.45 W/W
    • EER (Cooling, Btu/hW)11.76 Btu/hW
    • CSPF5.6
    • Energy Star Rating (Cooling)5 Star
  • Noise Level
    • Noise Level (Indoor, High/Low, dBA)40 / 20 dBA
    • Noise Level (Outdoor, High/Low, dBA)48 dBA
  • Electrical Data
    • Power Source(Φ/V/Hz)1 / 230 / 50
    • Power Consumption(Cooling, W)1020 W
    • Operating Current(Cooling, A)5.0 A
  • Physical specification
    • Gross Dimension (Indoor, WxHxD)886*317*335 mm
    • Gross Dimension (Outdoor, WxHxD)844*622*353 mm
    • Net Dimension (Indoor, WxHxD)828*267*265 mm
    • Net Dimension (Outdoor, WxHxD)720*548*265 mm
    • Gross Weight (Indoor, kg)10.4 kg
    • Gross Weight (Outdoor, kg)26.6 kg
    • Net Weight (Indoor, kg)8.9 kg
    • Net Weight (Outdoor, kg)24.3 kg
    • Loading Quantity (20/40/40Hft without Pipe)96 / 203 / 233
  • Technical Information
    • Piping Length (Max, m)15 m
    • Piping Height (Max, m)8 m
    • SVC Valve (Liquid (ODxL))6.35
    • SVC Valve (Gas (ODxL))9.52
    • Moisture Removal (l/hr)1.5 l/hr
    • Air Circulation (Cooling, ㎥/min)10.4 ㎥/min
    • Refrigerant (Type)R32
    • Refrigerant (Charging, kg)0.55 kg
    • Low Ambient (Cooling, ℃)16~46 ℃
    • Outdoor Unit (Compressor Type)8-POLE
    • Outdoor Unit (Anti-Corrosion Fin)Yes
  • Air Flow
    • Air Direction Control (Up/Down)Auto
    • Air Direction Control (Left/Right)Auto
    • Air Flow Control Step (Cool/Fan)5/4
  • Air Purification
    • IonizerYes
    • PM 2.5 FilterNo
    • Allergy CareYes
    • Anti-Bacteria ProtectorYes
    • Auto Clean (Self Cleaning)Yes
    • Easy filterNo
    • Easy Filter PlusYes
  • Convenience
    • Smart wifiYes
    • Filter Cleaning IndicatiorYes
    • Indoor Temp. DisplayYes
    • Display On/OffYes
    • Beep On/OffYes
    • 24-Hour TimerYes
    • Auto ChangeoverNo
    • Auto RestartYes
  • Operating Mode
    • 2 Step CoolingYes
    • Fast CoolYes
    • Comfort CoolYes
    • Dlight CoolNo
    • Good SleepYes
    • Single User ModeYes
    • DehumidificationYes
    • Fan ModeYes
    • QuietYes
  • Smart
    • WiFi EmbeddedYes
Description

Get Cool Fast,
Stay Cool without Direct
Wind

Wind-Free Cooling effectively maintains a comfortable level of coolness without the unpleasant feeling of cold wind. Cool air is gently dispersed through 21,000 micro air holes, so you don’t feel too hot or cold.

The image shows 21,000 micro air holes at the front panel of AR9500M

* Beaufort wind force scale defines “calm” as air currnets at speeds below 0.3m/s which lack the presence of cold drafts.

Saves energy
– up to 72%*

Digital Inverter 8-Pole

A Digital Inverter 8-Pole consumes only 32% of the energy used by conventional models*. It maintains the desired temperature without frequently turning off and on, so it’s much quieter, more durable and efficient.

*Tested on AR07M5170HA based on the accumulated power consumption of Fast Cooling mode vs Wind-Free™ Cooling mode.

Cools you down faster

Fast cooling

Quickly cools from corner to corner, so you’re always comfortable wherever you are. Digital Inverter 8-Pole technology cools the air 43% faster* and a triangular architecture disperses cool air farther and wider**.

Its unique triangle architecture has a 139% wider inlet, so more air can be drawn in. A 122% bigger fan and a 154% wider outlet also ensure that air is cooled and expelled faster, farther and wider.
* Tested on AR07M5170HA compared with Samsung conventional model ARN-CM63B.
** Tested on AR09FSSSBWK compared with Samsung conventional model AQV12TWS.

Control it anytime
& anywhere*

Wi-Fi Control using a Smart Things App

With the Wi-Fi Control using a Smart Things App* you can remotely control the functions and schedule its operation. It also gives you live feedback about how it’s operating and lets you monitor and limit power usage.

When user touches the power button of the smart home app, the air conditioner is turned on.
* Available on iPhones and Android devices. A network connection is required. A Samsung application account is necessary.

Enjoy a good night’s
sleep

Wind-Free Good Sleep mode

Good Sleep mode with Wind-Free Cooling creates the ideal climate for a good night’s sleep – without cold air flow. Its temperature control with Wind-Free cooling helps you fall asleep fast, sleep deeply, and wake refreshed.

Conventional

Wind-Free
Good Sleep mode

When using a conventional air conditioner, a user feels too cold from direct air flow. While using the Wind-Free air conditioner, user can enjoy comfortable environment without direct wind.

Keeps comfortable
without changing
settings

Wind-Free 2-Step Cooling mode

The 2-Step Cooling mode cools the air fast in Fast Cooling mode, then automatically changes to Wind-Free mode to maintain the temperature. So you stay comfortable, without cold spots, and don’t need to change settings.

Eco-
friendly
refrigerant

R32 Refrigerant

Uses the next generation R32 refrigerant, which has an Ozone Depletion Potential (ODP) of zero and a lower Global Warming Potential (GWP) than conventional refrigerants, so it is much more environmentally friendly*.

R32 Environmentally FriendlyA conventional refrigerant R22 has high Ozone Depletion Potential, and R410A has high Global Warming Potential. On the other hand, next generation refrigerant R32 has a low Global Warming Potential and also has an Ozone Depletion Potential of zero.
* Tested on R32 refrigerant compared with Samsung conventional refrigerant R410A and R22.

Reduces harmful viruses

Filtration System

Keeps the air you breathe pure and healthy. A Easy Filter captures dust, dangerous contaminants and allergens*. And Ionizer reduces certain harmful viruses and bacteria by up to 99%**.

* Tested in Korea test lab (FITI/KEMTI) and Japan test lab (ITEA). Data has been measured under specific testing conditions and results may vary based on environmental factors.
** Tested in Kitasato Environmental Science Center (Japan)

Quick &
easy to
clean filter

Easy Filter Plus

The Easy Filter Plus is located outside, on the top, so it can easily be taken out, cleaned and put back – without opening a cover. And its anti-bacterial coating filters dust, airborne contaminants and allergens*.

Easy Filter Plus can easily be taken out without opening a cover or pull hard to get it out.
* Tested in Korea test lab (FITI/KEMTI) and Japan test lab (ITEA). Data has been measured under specific testing conditions and may vary based on environmental factors.

Stable,
long-lasting
performance

Triple Protector Plus

Keeps going in the most challenging environments with Triple Protector Plus technology. It prevents overloads, without a separate voltage stabilizer*, has an anti-corrosion coating, and can endure harsh conditions.

An outdoor unit can endure harsh conditions
* Tested on AR09HPSDDWK/SG compared with Samsung conventional model AR09HPSDFAP/RC.
  • Capacity
    • Capacity (Cooling, Btu/hr)12000 Btu/hr
    • Capacity (Cooling, Min – Max, Btu/hr)4,000 ~ 14,000 Btu/hr
    • Capacity (Cooling, kW)3.52 kW
    • Capacity (Cooling, Min – Max, kW)1.17 ~ 4.1 kW
  • Energy Efficiency
    • EER (Cooling, W/W)3.45 W/W
    • EER (Cooling, Btu/hW)11.76 Btu/hW
    • CSPF5.6
    • Energy Star Rating (Cooling)5 Star
  • Noise Level
    • Noise Level (Indoor, High/Low, dBA)40 / 20 dBA
    • Noise Level (Outdoor, High/Low, dBA)48 dBA
  • Electrical Data
    • Power Source(Φ/V/Hz)1 / 230 / 50
    • Power Consumption(Cooling, W)1020 W
    • Operating Current(Cooling, A)5.0 A
  • Physical specification
    • Gross Dimension (Indoor, WxHxD)886*317*335 mm
    • Gross Dimension (Outdoor, WxHxD)844*622*353 mm
    • Net Dimension (Indoor, WxHxD)828*267*265 mm
    • Net Dimension (Outdoor, WxHxD)720*548*265 mm
    • Gross Weight (Indoor, kg)10.4 kg
    • Gross Weight (Outdoor, kg)26.6 kg
    • Net Weight (Indoor, kg)8.9 kg
    • Net Weight (Outdoor, kg)24.3 kg
    • Loading Quantity (20/40/40Hft without Pipe)96 / 203 / 233
  • Technical Information
    • Piping Length (Max, m)15 m
    • Piping Height (Max, m)8 m
    • SVC Valve (Liquid (ODxL))6.35
    • SVC Valve (Gas (ODxL))9.52
    • Moisture Removal (l/hr)1.5 l/hr
    • Air Circulation (Cooling, ㎥/min)10.4 ㎥/min
    • Refrigerant (Type)R32
    • Refrigerant (Charging, kg)0.55 kg
    • Low Ambient (Cooling, ℃)16~46 ℃
    • Outdoor Unit (Compressor Type)8-POLE
    • Outdoor Unit (Anti-Corrosion Fin)Yes
  • Air Flow
    • Air Direction Control (Up/Down)Auto
    • Air Direction Control (Left/Right)Auto
    • Air Flow Control Step (Cool/Fan)5/4
  • Air Purification
    • IonizerYes
    • PM 2.5 FilterNo
    • Allergy CareYes
    • Anti-Bacteria ProtectorYes
    • Auto Clean (Self Cleaning)Yes
    • Easy filterNo
    • Easy Filter PlusYes
  • Convenience
    • Smart wifiYes
    • Filter Cleaning IndicatiorYes
    • Indoor Temp. DisplayYes
    • Display On/OffYes
    • Beep On/OffYes
    • 24-Hour TimerYes
    • Auto ChangeoverNo
    • Auto RestartYes
  • Operating Mode
    • 2 Step CoolingYes
    • Fast CoolYes
    • Comfort CoolYes
    • Dlight CoolNo
    • Good SleepYes
    • Single User ModeYes
    • DehumidificationYes
    • Fan ModeYes
    • QuietYes
  • Smart
    • WiFi EmbeddedYes
