SUMMARY
-
- CAPACITY
- 12000 BTU
-
- DIMENSIONS (W X H X D)
- 837 x 308 x 189
-
- COMPRESSOR
- Inverter Compressor With 10 Year Warranty
-
- FEATURE
- Energy Saving & Fast Cooling
-
- Cooling Capacity
- 3,517W/12,000Btu/h.
- Max Cooling Capacity
- 13,600Btu/h.
-
- Power Input (Cooling)
- 1,095W
- Running Current (Cooling)
- 5.8A
-
- EER
- 3.21W/W/10.96Btu/h.W
- Power Supply
- 1/220-240V/50Hz
-
- Air Flow Rate (Indoor, Max)
- 13.0m³/min
- Air Flow Rate (Outdoor, Max)
- 28.0m³/min
-
- Moisture Removal
- 0.9l/h.
- Sound Level (Indoor, H/M/L/SL)
- 40/34/26/20 dB (A)
-
- Sound Level (Outdoor, Max )
- 50dB (A)
- Refrigerant (Type)
- R410A
-
- Refrigerant (Charge (at 7.5 m))
- 670g
- Additional Refrigerant Charge
- 20g/m
-
- Power Supply Cable
- 3 x 1.0 (No x mm²)
- Power and Communication Cable
- 4 x 1.0 (No x mm²)
-
- Piping Connections (Liquid Side)
- 6.35mm
- Piping Connections (Gas Side)
- 9.52mm
-
- Drain Hose Size (O.D/I.D)
- 21.5/16.0 (0.85/0.62) mm (in)
- Pipe Length (Standard/Max)
- 7.5/15 (24.6/49.2) m (ft)
-
- Fan (Indoor) Type
- Cross Flow Fan
- Fan (Outdoor) Type
- Fan, Propeller
-
- Dimensions (Indoor (WxHxD))
- 837 x 308 x 189 mm
- Dimensions (Outdoor (WxHxD))
- 720 x 500 x 270 mm
-
- Net Weight (Indoor)
- 8.9 (19.6) kg (lb)
- Net Weight (Outdoor)
- 23.5 (51.8) kg (lb)
