Operating systems
Specification
|
Description
|
Preinstalled
|
Windows 10 Pro 64 (National Academic only)
Windows 10 Pro 64
Windows 10 Home 64
Windows 10 Pro (Windows 10 Enterprise available with a Volume Licensing Agreement)
Windows 10 Home Single Language 64
FreeDOS 1.2
|
NOTE:
In accordance with Microsoft support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation or later processors, or provide any Windows 8 or Windows 7 drivers.
Processors
Specification
|
Description
|
Intel Core i7-10510U processor
|
1.8 GHz base frequency, up to 4.9 GHz with Intel Turbo Boost Technology
8 MB L3 cache and 4 cores
Intel UHD Graphics 620
|
Intel Core i5-10210U processor
|
1.6 GHz base frequency, up to 4.2 GHz with Intel Turbo Boost Technology
6 MB L3 cache and 4 cores
Intel UHD Graphics 620
|
Intel Core i3-10110U processor
|
2.1 GHz base frequency, up to 4.1 GHz with Intel Turbo Boost Technology
4 MB L3 cache and 2 cores
Intel UHD Graphics 620
|
Chipset
|
Integrated with processor
|
NOTE:
Multicore is designed to improve performance of certain software products. Not all customers or software applications necessarily benefit from use of this technology. Performance and clock frequency vary depending on application workload and hardware and software configurations. Intel numbering is not a measurement of higher performance.Processor speed denotes maximum performance mode; processors run at lower speeds in battery optimization mode.Intel Turbo Boost performance varies depending on hardware, software, and overall system configuration.
Graphics
Specification
|
Description
|
Integrated
|
Intel UHD Graphics 620
|
Discrete
|
NVIDIA GeForce MX130 (2 GB DDR5 dedicated)
NVIDIA GeForce MX250 (2 GB DDR5 dedicated)
|
Supported
|
Supports HD decode, DirectX12, and HDMI 1.4b up to 4K at 30Hz
Supports CUDA, Optimus, PhysX, and GPU Boost 2.0
|
Display
Specification
|
Description
|
Non-touch
|
39.62 cm (15.6 in) diagonal HD SVA eDP anti-glare slim, 220 nits, 45% NTSC for two WLAN antennas (1366 x 768)
39.62 cm (15.6 in) diagonal HD SVA eDP anti-glare slim, 220 nits, 45% NTSC for HD camera and two WLAN antennas (1366 x 768)
39.62 cm (15.6 in) diagonal HD SVA eDP anti-glare slim, 220 nits, 45% NTSC for HD and IR camera and two WLAN antennas (1366 x 768)
39.62 cm (15.6 in) diagonal HD SVA eDP anti-glare slim, 220 nits, 45% NTSC for HD camera, WWAN, and two WLAN antennas (1366 x 768)
39.62 cm (15.6 in) diagonal FHD IPS eDP anti-glare slim, 250 nits, 45% NTSC for two WLAN antennas (1920 x 1080)
39.62 cm (15.6 in) diagonal FHD IPS eDP anti-glare slim, 250 nits, 45% NTSC for HD camera and two WLAN antennas (1920 x 1080)
39.62 cm (15.6 in) diagonal FHD IPS eDP anti-glare slim, 250 nits, 45% NTSC for HD and IR camera and two WLAN antennas (1920 x 1080)
39.62 cm (15.6 in) diagonal FHD IPS eDP anti-glare slim, 250 nits, 45% NTSC for HD camera, WWAN, and two WLAN antennas (1920 x 1080)
39.62 cm (15.6 in) diagonal FHD IPS eDP and PSR anti-glare flat with HP Sure View Integrated Privacy Screen, 1000 nits, 72% NTSC for HD camera and two WLAN antennas (1920 x 1080)
39.62 cm (15.6 in) diagonal FHD IPS eDP and PSR anti-glare flat with HP Sure View Integrated Privacy Screen, 1000 nits, 72% NTSC for HD and IR camera and two WLAN antennas (1920 x 1080)
|
Touch
|
39.62 cm (15.6 in) diagonal FHD IPS eDP On-Cell slim touchscreen, 250 nits, 45% NTSC for HD camera and two WLAN antennas (1920 x 1080)
39.62 cm (15.6 in) diagonal FHD IPS eDP On-Cell slim touchscreen, 250 nits, 45% NTSC for HD camera, WWAN, and two WLAN antennas (1920 x 1080)
|
HDMI
|
Supports resolutions up to 4K at 30 Hz
|
NOTE:
High-definition (HD) content is required to view high definition images.Resolutions are dependent upon monitor capability, and resolution and color depth settings.HP Sure View integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation.
Storage/drives
Specification
|
Description
|
Primary M.2 Solid State Drive storage
|
128 GB M.2 SATA TLC SSD
256 GB PCIe NVMe M.2 Value SSD
256 GB Intel PCIe NVMe QLC M.2 SSD with 16 GB Intel Optane memory H10
512 GB PCIe NVMe M.2 TLC SSD
512 GB PCIe NVMe M.2 Value SSD
512 GB Intel PCIe NVMe QLC M.2 SSD with 32 GB Intel Optane memory H10
|
Primary SATA hard drives
|
500 GB 7200 RPM
1 TB 5400 RPM
|
NOTE:
For solid state drives or hard drives, GB = 1 billion bytes; TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software.
Memory
Specification
|
Description
|
Standard
|
DDR4-PC4 SODIMMS
Supports dual-channel memory
(2) Dual-channel SODIMM slots (both slots are customer accessible/upgradable)
Runs at 2400 MT/s for Intel 8th generation processors
|
Configurations
|
32 GB DDR4-2666 SDRAM (16 GB x 2)
16 GB DDR4-2666 SDRAM (16 GB x 1)
12 GB DDR4-2666 SDRAM (8 GB x 1 and 4 GB x 1)
8 GB DDR4-2666 SDRAM (8 GB x 1)
8 GB DDR4-2666 SDRAM (4 GB x 2)
4 GB DDR4-2666 SDRAM (4 GB x 1)
|
Maximum
|
32 GB
|
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If memory speeds are mixed, the system performs at the lower memory speed.
Ports/slots
Specification
|
Description
|
Ports
|
(1) USB 3.1 Type-C Gen 1 connector (Power Delivery, DisplayPort)
(2) USB 3.1 Gen 1
(1) USB 2.0 (Powered port)
(1) RJ-45
(1) Headphone/microphone combo jack
(1) AC power port
(1) HDMI 1.4b
|
Slot
|
(1) Standard security lock
(1) SD Card reader
|
Networking/communication
Specification
|
Description
|
Wireless LAN (WLAN)
|
Intel Dual Band Wireless-AC 9560 802.11a/b/g/n/ac (2×2) WLAN and Bluetooth 5 Combo, non-vPro
Intel Dual Band Wi-Fi 6 AX201 802.11a/b/g/n/ac (2×2) WLAN and Bluetooth 5 Combo, non-vPro
Realtek 802.11ac (2×2) WLAN and Bluetooth 5 Combo
|
WWAN
|
Intel XMM 7360 LTE-Advanced (Cat9)
|
Ethernet
|
Realtek 10/100/1000 GbE NIC
|
Audio/multimedia
Specification
|
Description
|
Audio
|
Integrated microphone (mono or dual-array)
(2) Integrated stereo speakers
|
Speaker power
|
2 W/4 ohm per speaker
|
Camera
|
720p HD camera
720p HD and IR camera (sold separately)
|
Keyboards/pointing devices/function keys
Specification
|
Description
|
HP Premium keyboard
|
Spill-resistant with optional backlit function
|
Pointing device
|
Clickpad with multi-touch gesture support
|
Function keys
|
Function keys
F1 – Display switching
F2 – Blank or SureView On/Off
F3 – Brightness down
F4 – Brightness up
F5 – Audio mute
F6 – Volume down
F7 – Volume up
F8 – Microphone mute
F9 – Blank or backlight toggle
F10 – Num lock
F11 – Wi-Fi toggle
F12 – Sleep
Hidden functions
Fn+R – Break
Fn+S – System Rq
Fn+C – Scroll Lock
|
Software/security
Specification
|
Description
|
BIOS
|
HP BIOSphere Gen5 (requires Intel 8th generation processors)
HP Sure Start Gen5 (requires Intel 8th generation processors)
HP DriveLock/HP Automatic DriveLock
BIOS Update via Network
Master Boot Record Security
Secure Erase (methods outlined in the National Institute of Standards and Technology Special Publication 800-88)
Pre-boot Authentication
Absolute Persistence Module
|
Communication/connectivity
|
HP Connection Optimizer
|
HP Value add software
|
HP Hotkey Support – CMIT
HP Image Assistant
HP Jumpstart
HP Support Assistant (requires Windows and internet access)
HP Noise Cancellation software
|
Microsoft products
|
Buy Office (sold separately)
|
Manageability
|
HP Driver packs (available for download)
HP System Software Manager (SSM) (available for download)
HP BIOS Configuration Utility (BCU) (available for download)
HP Client Catalog (available for download)
HP Management Integration Kit Gen3 for Microsoft SCCM (available for download)
|
Client Security software
|
HP Security Manager (including Credential Manager and HP Password Manager, and HP Spare Key)
HP Fingerprint Sensor (sold separately or as an optional feature)
Power On Authentication
Microsoft Defender (opt in and internet connection required for updates)
|
Security
|
For Windows 10, Trusted Platform Module (TPM) 2.0 (Infineon SLB9670)
Common Criteria EAL4+ Certified
HP Client Security Manager Gen5
HP Fingerprint Reader (sold separately or as an optional feature)
Secure Erase
|
Other standard security features
|
Serial, USB enable/disable (via BIOS)
Power-on password (via BIOS)
Setup password (via BIOS)
HP Sure Click
Support for chassis padlocks and cable lock devices
|
Power
Specification
|
Description
|
Power supply
|
Adapters
HP Smart 65 W External AC power adapter
HP Smart 65 W EM External AC power adapter
HP Smart 65 W USB Type-C adapter
HP Smart 45 W External AC power adapter
HP Smart 45 W USB Type-C adapter
Power cords
3-wire plug – 1 m (3.28 ft)
3-wire plug – 1.8 m (5.9 ft)
2-wire plug – 1 m (3.28 ft)
Duckhead power cord – 1 m (3.28 ft)
Duckhead power cord – 1.8 m (5.9 ft)
|
Primary battery
|
HP Long Life 3-cell, 45 Wh Li-ion
|
Battery weight
|
0.22 kg (0.49 lb)
|
Physical specifications
Specification
|
Description
|
Weight
|
Non-touch
Starting at 2 kg (4.41 lb)
Touch
Starting at 2.03 kg (4.48 lb)
|
Dimensions (W x D x H)
|
36.50 x 25.68 x 1.91 cm (14.37 x 10.11 x 0.75 in)
|
